Drawing 09-1200

Bildnr

Part number

Quantity

Description

Description_de

1

49646040

1

Engine

Motor

2

50100598

2

Bolt

Schraube

3

28895640

2

Bracket

Lagerbock

4

28895540

2

Cover

Abdeckblech

5

28895940

6

Washer

Scheibe

6

32744240

2

Mounting

Motorlager

7

34311299

16

Lock washer

Federring

8

32560799

8

Bolt

Schraube

10

43552240

2

Bracket

Lagerbock

11

28895740

2

Rubber pad

Gummilager

12

33233499

8

Nut

Mutter

14

30780599

8

Bolt

Schraube

15

33233499

8

Nut

Mutter

16

30782399

4

Bolt

Schraube

17

34311699

4

Lock washer

Federring

18

33222699

4

Nut

Mutter

19

51170698

4

Bolt

Schraube

31

-

1

Hydr. pump see page 90-1594,etc.

Hydraulikpumpe s. el-blatt 90-1594,etc.

32

39475240

1

Gear pump

Zahnradpumpe

33

39472440

1

Clutch assy. incl. fig-no. 34

Kupplung kpl. einschl. bild-nr. 34

34

592065

1

Elastic intermediate ring

Elast. zwischenring

35

32746840

1

Intermediate ring

Zwischenring

36

30777999

24

Bolt

Schraube

37

30857599

12

Bolt

Schraube

38

30761299

2

Bolt

Schraube

39

34650099

36

Lock washer

Federring

40

34650299

4

Lock washer

Federring

41

50180698

1

Seal

Dichtung

50

66483940

1

Oil filler

^leinfullstutzen

51

31859799

1

Bolt

Schraube

52

50401498

1

Lock washer

Federring

53

33211099

1

Nut

Mutter
