Drawing 09-1290

Bildnr

Part number

Quantity

Description

Description_de

1

60238340

1

Console

Konsole

2

59297740

1

Solenoid valve

Magnetventil

3

18022140

1

Switching relay

Schaltrelais

4

30773099

12

Bolt

Schraube

5

59297840

1

Ball joint

Kugelgelenk

6

33211099

16

Nut

Mutter

7

63872540

1

Threaded rod

Gewindestange

8

63872640

1

Threaded rod

Gewindestange

9

30025799

2

Angle joint

Winkelgelenk

10

63872740

1

Adapter

Adapter

11

63872840

1

Lever

Hebel

12

34649999

12

Lock washer

Federring

13

26455740

1

Slave cylinder

Nehmerzylinder

14

46988240

1

Draw spring

Zugfeder

15

33211199

3

Nut

Mutter

16

63872940

1

Retainer

Halter

17

63873040

1

Lever

Hebel

18

63873140

1

Retainer

Halter

19

30742799

1

Bolt

Schraube

20

30730699

1

Bolt

Schraube

21

34309499

2

Lock washer

Federring

22

50928498

2

Bolt

Schraube

23

34309599

2

Lock washer

Federring

24

30746699

2

Bolt

Schraube

25

33233499

2

Nut

Mutter

26

50427198

2

Lock washer

Federring
