Bildnr
Part number
Quantity
Description
Description_de
01
1
Dash board see page 39-2110, etc.
Armaturenbrett s. el-blatt 39-2110, etc.
04
1
Spotlight
Arbeitsscheinwerfer
-
-
Bulb to fig-no: 04
Gluhlampe zu bild-nr. 04
05
1
Spotlight
Arbeitsscheinwerfer
-
-
Bulb to fig-no: 05
Gluhlampe zu bild-nr. 05
06
1
Main calculator incl. operation panel
Zentraleinheit inkl. bedienkonsole
07
1
Bus coupler
Buskoppler (a110 - a111)
08
1
Socket
Steckdose 2-polig
09
2
Tapping screw
Blechschraube
10
1
Push button switch
Druckknopfschalter
12
2
Lock washer
Federring
13
1
Cable sleeve
Kabelmuffe
14
1
Female housing, grey
Steckhulsengehause 8-polig, grau
15
1
Female housing, brown-beige
Steckhulsengehause 8-polig, braun-beige
16
16
Sleeve contact
Steckhilsenkontakt
17
1
Socket
Steckergehause, 15-polig
19
3
Male contact
Stiftkontakt
20
1
Female housing
Steckhilsengehause, 4-polig
22
2
Fitting
Anschlubarmatur
23
-
Cable protection pipe - state length required
Kabelschutzwellrohr nw 70 - lange angeben
25
8
Lock washer
Federring
27
1
Assembly rail
Tragschiene
29
1
Cover plate
Abschlubplatte
31
-
Cable - state lenght required
Kabel 3x1, lange angeben
32
1
Series terminal
Reihenklemme
41
1
Plate front, i.h.
Blech vorne, links
42
1
Plate front, r.h.
Blech vorne, rechts
43
1
Console plate lower, i.h.
Konsolenplatte unten, links
44
1
Console plate lower, r.h.
Konsolenplatte unten, rechts
45
12
Countersunk screw
Senkschraube
48
8
Lock washer
Federring
51
2
Transmitter
Signalgeber
54
-
Cable, state lenght required
Kabel 18x0,5, lange angeben
55
2
Female housing
Steckhulsengehause
-
1
Radio with recorder
Autoradio mit recorder
